M4 thread hole，
Low thermal EMF down to<3μV/°C，
power rating up to 50W，
AEC-Q200 qualified available.
RoHS compliant
Patented pin structure can sense ultra-low and high accuracy voltage.
| Datasheet | MODEL | Image | POWER ( W ) |
RESISTANCE VALUE RANGE ( mΩ ) |
TCR （ppm/℃) |
TOLERANCE ( % ) |
 |
HYCS6918 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS8518 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS8420 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS8536 |  |
50W | 0.02mΩ-0.05mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS9420 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS6918..P |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS8518..P |  |
Max.36W | 0.05mΩ-0.25mΩ | ±100 | ±1%(F) ±5%(J) |
|
HYCS8536..P |  |
50W | 0.02mΩ-0.05mΩ | ±100 | ±1%(F) ±5%(J) |
|
PACS6820 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±75 | ±1%(F) ±5%(J) |
|
PACS8420 |  |
Max.36W | 0.05mΩ-0.25mΩ | ±75 | ±1%(F) ±5%(J) |
|
PACS8536 |  |
50W | 0.02mΩ-0.05mΩ | ±75 | ±1%(F) ±5%(J) |
